TheSky Professional Supported Telescopes

The table below lists the "go to" and "push to" telescope models supported by TheSky Professional.  For step-by-step setup instructions on how to setup and control telescopes with TheSky, see Telescope Control in TheSky Professional and Serious Astronomer User Guide.

Connect

Center Cross Hairs

Add Telrad™ Finder to Sky Chart

Stop Slew

Telescope Limits

Star Synchronization

Spiral Search

Park mount

Manufacturer

Series

Model Number

Astro-Physics™

GTO series mounts

The following models are supported::

• Mach1GTO

• 900GTO

• 1200GTO

• 3600GTO

Celestron International™

Advanced Series

All models, including:

• CG5-SGT

• C6-RGT

• C8-SGT

• C8-NGT

• C9.25-SGT

• C-10 NGT

• C-11 SGT

Advanced VX Mounts

All models

CGEM Series

All models, including:

• CGEM 800

• CGEM 925

• CGEM 1100

CGE Series

All models, including:

• CGE 800

• CGE 925

• CGE 1100

• CGE 1400

CPC Series

All models, including:

• CPC 800

• CPC 800 XLT

• CPC 900

• CPC 900 XLT

• CPC 1100

• CPC 1100 XLT

GT Series

All models, including:

• NexStar 60GT

• NexStar 76GT

• NexStar 80GT

• NexStar 102GT

• NexStar 114GT

• NexStar 130GT

• NexStar 4GT

NexStar GPS

All models, including

• NexStar 8 GPS

• NexStar 9.25

• NexStar 11 GPS

i Series

All models, including:

• NexStar 5i

• NexStar 8i

NexStar (non-GPS)

All models, including:

• NexStar 4

• NexStar 5

• NexStar 8

SE Series

All models, including:

• NexStar 4 SE

• NexStar 5 SE

• NexStar 6 SE

• NexStar 8 SE

Sky Prodigy Series

All models

Ultima 2000*

*Software Bisque considers the Celestron Ultima 2000 telescope a "legacy" product as relatively few of these telescopes are still in use.

While TheSky includes a driver for the Ultima 2000, we no longer provide technical support when using TheSky to control this mount.

iOptron

Cube II EQ mode

Cube II AA mode

Cube Pro EQ mode

Cube Pro AA mode

SmartEQ Pro+

CEM25(/P)

CEM25-EC

iEQ30 Pro

CEM40

CEM40-EC

GEM45

GEM45-EC

iEQ45 Pro EQ mode

iEQ45 Pro AA mode

CEM60

CEM60-EC

CEM120

CEM120-EC

CEM120-EC2

All models

See TheSky Professional and Serious Astronomer User Guide for details about setting up and using iOptron mounts.

iOptron occasionally releases newer versons of their telescope command protocol.

• Version 1.0*

• Version 2.0

• Version 2.5

• Version 3.0

• Version 3.01

Notes:

• * Earlier model Optron SmartStar mounts used the Silicon Labs CP210X USB to UART Bridge for serial communications on macOS and Windows.  This UART requires a Virtual Serial Port Driver to be installed before TheSky can communicate with these model mounts.  The CP210x USB to UART Bridge VCP Drivers (VCP Driver Kit) are available from the Silicon Labs web site.

• iOptron mounts using the serial command protocol version 2 and later do not require installation of a VCP driver.

Losmandy Astronomical Products™

German Equatorial Mounts

All models, including:

• Losmandy GM-8

• Losmandy G11

• Losmandy HGM-200

• Losmandy HTM-Titan

• Mathis Instruments MI-250

Lumicon™

NGC Sky Vector and Sky Commander

All models

Mathis Instruments™

MI Series Mounts

All modes, including:

• MI-500

• MI-750

• MI-1000

Mathis Instruments mounts use either the Gemini Astronomical Positioning System or the Bisque TCS (TheSky Professional only).

Meade Instruments™

LX200™ (classic)

All models, including:

• 8-inch LX200

• 8-inch LX10

• 8-inch LX90

• 10-inch LX200

• 12-inch LX200

• 16-inch LX200

Autostar

All models, including:

• ETX*

• ETX 90

• ETX 90 AT

• ETX 105 AT

• ETX 125 AT

*Requires Meade Autostar Computer Controller #497 with RS232 serial port.

LX200 GPS Series (Autostar II)

All models, including:

ACF Models

• 8-inch LX200-ACF

• 10-inch LX200-ACF

• 12-inch LX200-ACF

• 14-inch LX200-ACF

• 16-inch LX200-ACF

SCTs

• 7-inch LX200 GPS Mak-Cass

• 8-inch LX-90 SCT

• 8-inch LX200 GPS

• 10-inch LX200 GPS

• 12-inch LX200 GPS

• 14-inch LX200 GPS

• 16-inch LX200 GPS

"Ritchey-Chrétian"

• 10-inch RCX400

• 12-inch RCX400

• 14-inch RCX400

• 16-inch RCX400

Mountain Instruments

MI-250 Equatorial Mounts

Mountain Instruments mounts use Gemini Astronomical Positioning System for go to telescope control.

Orion® Telescopes & Binoculars

Atlas™ EQ-G Equatorial Mounts

This mount uses the same control system (and the same serial communication protocol) as the NexStar GPS and other later model Celestron International "go to" telescopes.

Sirius™ EQ-G Equatorial Mounts

This mount uses the same control system (and the same serial communication protocol) as the NexStar GPS and other later model Celestron International "go to" telescopes.

SkyQuest IntelliScope

See Tangent Instruments Device Support below

Ouranos

All models

René Görlich/Gemini

Gemini Astronomical Positioning System

All models, including:

• Losmandy GM-8

• Losmandy G11

• Losmandy Titan

• Losmandy HGM-200

• Mathis Instruments MI-250

Sky Comm Engineering™

Sky Commander and Sky Commander XP4 Flash

All models, including these models:

• Digital Setting Circles by Losmandy

• NGC Sky Commander by Lumicon

Sky-Watcher™

Sky-Watcher™ Mounts

All models that use the SynScan Controller, including:

• HEQ5 Pro German equatorial mount

• EQ6 Pro German equatorial mount

• NEQ3

• EQ5

The SkyWatcher mounts use the SynScan control system for go to control; the SynScan control system uses the NexStar 5 communications protocol via RS232.

See USB Adapters for more information about physically connecting your mount to your computer.

Software Bisque™

BBox

Software Bisque's BBox (manufactured by Tangent Instruments) that started the "push to telescope" revolution in 1988.

Paramount ME Robotic Telescope Mount (Legacy)

Paramount Robotic Telescope Mounts

All models, including:

• Paramount MYT gear driven GEM
• Paramount MX gear driven GEM
• Paramount MX+ gear driven GEM
• Paramount ME II gear driven GEM
• Paramount Taurus 400 gear driven equatorial fork
• Paramount Taurus 600/700/800 direct drive equatorial fork
• Paramount Apollo 600/800 direct drive altazimuth

Star Pilot

All models

Takahashi™

Temma

The following models are supported:

• EM-10 Temma PC Jr. (USD2)

• EM-200 Temma PC Jr. (USD2)

• EM-200 Temma PC

• NJP Temma PC

• EM-500 Temma PC

• EM-10 Temma2 Jr. (USD3)

• EM-200 Temma2 Jr. (USD3)

• EM-11 Temma2 Jr. (USD3)

• EM-200 Temma2

• EM-400 Temma2

• EM-500 Temma2

Tangent Instruments™

Encoder-to-serial boxes

All models, including:

• Advanced Astromaster by Celestron

• BBox by Software Bisque

• Deep Space Navigator

• NGC-MAX by Jim's Mobile, Inc.

• Ouranos

• Sky Wizard 2 by Orion Telescopes & Binoculars

• Sky Wizard 3 by Orion Telescopes & Binoculars

• SkyQuest IntelliScope by Orion Telescopes & Binoculars

• Sky Tour by Tele Vue

• Sky Vector by Lumicon

• StarPilot

Vixen™

Sky Sensor

All models

STAR BOOK Star-Chart Go To System

TheSky Professional mounts that use the STAR BOOK Star-Chart Go To System, including (but not limited to) the following models:

• Atlux equatorial mount

• Sphinx SXC equatorial mount

• Sphinx SXD equatorial mount

• Sphinx SXW equatorial mount

If your specific telescope model is not listed, but uses the Vixen STAR BOOK Star-Chart Go To System, TheSky Pro and Serious can control it.

Wildcard Innovations™

Argo Navis

All models

Device Name

Model Number

AstroTrac™

AstroTrac 360 GEM

Astrometric Instruments' Astrometric Telescope Control System™ (ATCS)2

Mounts using the Astrometric Instruments Telescope Control System

iOptron™ Mounts using the version 3 serial command protocol2

CEM120xx model mounts

Gemini Telescope Design Pulsar™ GoTo Controller2

Mounts using the Pulsar GoTo controller

Sky-Watcher™ Mounts with EQDIR cable3

EQ6, HEQ5, EQ5, EQ3, EQ8, and the AZEQ5 and AZEQ6 in EQ mode only.

Driver Model

Model Number

ASCOM (Windows only)

TheSky Professional for Windows can control any telescope mount that has an ASCOM-compatible driver.  The Windows-only ASCOM platform and the Windows-only ASCOM-specific telescope driver must be downloaded and installed separately.

-

-

-
